DESCRIPTION
The HUGO LED Medical Examination Light is designed to provide illumination of the body of a patient for localized diagnosis and treatment. The light is not designed for use during surgery. It is designed for continuous operation and it must be possible to stop the treatment or diagnosis without danger to the patient if the light fails during use. The device is intended to be used by doctors/medical practitioners and nursing staff.
PRODUCT USE:
Normal Care to High Care Wards, Medical Consultation Rooms, Intensive Care Units, Trauma Units, Nursing Homes and Clinics.
DESIGN
- 5 LEDs
- Lamp body/housing (All plastic parts): Plastic moulded.
- Arm: Aluminium: Natural anodised
- Operating Reach: 1700 mm to centre of light source
- Dimming function: Progressive dimming
- IP Rating: 54
LUX OUTPUT
35 000 Lux @ 1000 mm / 50 000 Lux @ 500 mm
INSTALLATION
Pre-fitted with 1.5m cable and moulded plug top;
The unit is manufactured, tested and validated against international standards prior to installation.
STANDARDS & SPECIFICATIONS
IEC 60601-1
IEC 60601-1-2
IEC 60601-2-41
IEC 62031
